U-ANG-ADP-6R12-3T4
Adjustable Angle Tubing Connection, joins (2) 3 in to 4 in OD round members between 60 and 120 degrees
Specifications
Product classification
| Product Type | Magnetic mount |
| Product Brand | Estech Magnetics |
| Ordering Note | ANDREW® non-standard product |
General specifications
| Mounting | Water tower surface |
Dimensions
| Height | 264.668 mm | 10.42 in |
| Width | 179.324 mm | 7.06 in |
| Length | 366.776 mm | 14.44 in |
Material specifications
| Material Type | Stainless steel |
Packaging and weights
| Packaging quantity | 1 |
| Weight, net | 9.943 kg | 21.92 lb |
Product classification
| Product Type | Magnetic mount |
| Product Brand | Estech Magnetics |
| Ordering Note | ANDREW® non-standard product |
General specifications
| Mounting | Water tower surface |
Dimensions
| Height | 264.668 mm | 10.42 in |
| Width | 179.324 mm | 7.06 in |
| Length | 366.776 mm | 14.44 in |
Material specifications
| Material Type | Stainless steel |
Packaging and weights
| Packaging quantity | 1 |
| Weight, net | 9.943 kg | 21.92 lb |
